Light Weight Angle Steel Roll Forming Machine With Continuous Punching System

Light Weight Angle Steel Roll Forming Machine With Continuous Punching System

Steel Stud Roll Forming Machine

Metal Stud Roll Forming Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-ST45

Contact Us

Request A Quote
Product Details
Product Description



Light Weight Angle Steel Roll Forming Machine With Continuous Punching System





  Main Specifications of Wall Angle Roll Forming Machine





  • Material: G.i Coil
  • Material Thickness:0.4-1.0mm
  • Main Power: 4KW
  • Hydraulic power: 4KW
  • Forming Station: about 6 stations ( adopt Italy Technology )
  • Axis Diameter: ¢ 70 mm
  • Forming Speed: 0-15m/min
  • Forming Frame Structure: Guiding Column + Slide Blocks; This forming frame structure design is much high precision than wall plate welding structure
  • PLC Brand: PANASONIC Brand
  • Machine Diameter: about 7000mm(L)x800mm(W)x1300mm (H)
  • Weight of machine: about 4 Ton
  • Voltage: 380V, 3 Phase 50Hz ( or depend on customer’s requirement )







  Reference Drawings















Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 0Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 1















  Applications





Metal stud and track, steel stud and track, c stud, u runner, u track, furring channel, roof ceiling batten, roof truss, c truss, light weight steel truss...





  Our Advantage



  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience







  Machine Picture







Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 2

Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 3

Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 4

Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 5







Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 6









  Certificate







Light Weight Angle Steel Roll Forming Machine With Continuous Punching System 7
