Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets

Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets
Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets

Large Image :  Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-FD1250
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Decoiler Type: Manual Or Hydraulic Type Main Motor Power: 18.5KW
Roller Stand: About 24 Stations (Depend On Final Design) Shaft Material: First Grade 45# Steel, Heated And Quenched
High Light:

Deck Roll Forming Machine

,

Floor Deck Roll Forming Machine

Galvanized Floor Deck Roll Forming Machine For Floow Decking Sheets





  Main Specifications of Floor Deck Roll Forming Machine



Raw material Galvanized steel sheets with strength 325Mpa
Material Thickness 0.8-1.2mm
Material Width 1220mm (depend on profile)
Decoiler Manual or Hydraulic type
Roller stand about 24 stations (Depend on final design)
Shaft diameter 90mm
Roller material Gcr15 steel, quenched and heated process, HRC58-62
Shaft material First grade 45# steel, heated and quenched
Main motor power 22KW
Hydraulic station power 3.0KW
Forming speed 10-12m/min
Cutting type Hydraulic cutting
Blade material Cr12 quenched treated
Hydraulic pressure 10-12Mpa
Controlling system PLC





  Main Components

  • Decoiler / Uncoiler-----------------------------------------------------------1 Unit
  • Feeding Device--------------------------------------------------------------1 Unit
  • Main Roll Forming Machine------------------------------------------------1 Unit
  • Hydraulic Cutting Device---------------------------------------------------1 Unit
  • Hydraulic Station------------------------------------------------------------1 Unit
  • PLC Computer Control-----------------------------------------------------1 Unit
  • Output Table------------------------------------------------------------------1 Unit





  Reference Drawings





Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets 0







  Application



Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...





  Our Advantage



1. Durable and widely used products

2. Simple to operate when assemble

3. Direct manufacturer, provide with high quality and best price.

4. Provide sample in free.

5. Products and design solution supplied fast and freely

6. Best design oriented for your special requirements







  Machine Picture





Galvanized Steel Floor Deck Roll Forming Machine For Floor Decking Sheets 1
