18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed

18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed

door frame roll forming machine

shutter door roll forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-DF100

Contact Us

Request A Quote
Product Details
Product Description





18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed








   Main Specifications







  • Roll Diameter: 75mm
  • Forming Roller stand: 18 Groups
  • Main Axis material: First grade 45# steel, heated and quenched
  • Roller material of Door Frame Roll Forming Machine: GCr15 Steel, Quenched and heated process
  • Forming Speed: 0-10 m/min
  • Dive Type: 1.2” Chain of transmission
  • Chain Material: 45# steel.
  • Machine Frame stand: Welded structural steel
  • Machine Base: 36# H steel
  • Thickmess of Fame Steel: 18mm
  • Main Power: 7.5KW





   Door Frame Profile Drawings









  • 18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed 0











   Main Components







  • Decoiler ---------------------------------------------- 1 Unit
  • Feeding & leveling------------------------------------ 1 Unit
  • Main roll forming machine --------------------------- 1 Unit
  • Hydraulic punching ----------------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------ 1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit









   Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience







   Roller  Shutter Door Forming Machine Pictures







18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed 1









  Factory Pictures





18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed 2







18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed 3









  Certificate









18 Forming Groups Window Frame Roll Forming Machine With 0 - 10m/min Forming Speed 4
