Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine

Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine

Garage Door Roll Forming Machine

door frame roll forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-RSD85

Contact Us

Request A Quote
Product Details
Product Description





Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine










   Main Specifications







  • Steel Sheet Thickness: 0.5-1.2mm or 1.5-2.5mm (depend on requirement )
  • Covered Width: 82.3mm ( depend on prfoile )
  • Coil Width: 134mm ( depend on prfoile )
  • Decoiler: Manual Decoiler
  • Capacity of Decoiler: 3 Ton
  • Forming Speed: 5-15m/min
  • Roller Groups: 13 stes main roller
  • Roller Material: CCr15 high grade steel with finish machining treatment, by high frequency quenched HRC58-62
  • Roller Diameter: 120mm
  • Principal Axis: 45# high grade steel with brewage treatment













   Applications





Rolling shutter door, shutter door, roller shutter door, shutter door slat...





   Roller Shutter Profile Drawing









Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine 0











  Main Components





  • Decoiler ----------------------------------------------- 1 Unit
  • Feeding ----------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station -------------------------------------- 1 Unit
  • PLC computer control --------------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit







   Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









   Roller  Shutter Door Forming Machine Pictures





Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine 1















  Factory Pictures









Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine 2

Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine 3

Manual Decoiler GCr15 High Grade Roller, 1.5 - 2.5mm Roller Shutter Roll Forming Machine 4
