0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed

China 0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed supplier
0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed supplier 0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed supplier

Large Image :  0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-RSD85

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description




0.5 - 1.2mm Thickness Steel Shutter Door Slat Roll Forming Machine With 5 - 15 m/min Speed







   Applications





Rolling shutter door, shutter door, roller shutter door, shutter door slat...





   Roller Shutter Profile Drawing









0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed







   Main Specifications





  • Steel Sheet Thickness: 0.5-1.2mm or 1.5-2.5mm (depend on requirement )
  • Covered Width: 82.3mm ( depend on prfoile )
  • Coil Width: 134mm ( depend on prfoile )
  • Decoiler: Manual Decoiler
  • Capacity of Decoiler: 3 Ton
  • Forming Speed: 5-15m/min
  • Roller Groups: 13 stes main roller
  • Roller Material: CCr15 high grade steel with finish machining treatment, by high frequency quenched HRC58-62
  • Roller Diameter: 120mm
  • Principal Axis: 45# high grade steel with brewage treatment







  Main Components





  • Decoiler ----------------------------------------------- 1 Unit
  • Feeding ----------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station -------------------------------------- 1 Unit
  • PLC computer control --------------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit







   Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









   Roller  Shutter Door Forming Machine Pictures









0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed











  Factory Pictures









0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed

0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed

0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed









0.5 - 1.2mm Thickness Steel Roller Shutter Forming Machine With 5 - 15 m/min Speed
