Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-RSD85
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
High Light:

Garage Door Roll Forming Machine

,

door frame roll forming machine





High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller









   Main Specifications







  • Steel Sheet Thickness: 0.5-1.2mm or 1.5-2.5mm (depend on requirement )
  • Covered Width: 82.3mm ( depend on prfoile )
  • Coil Width: 134mm ( depend on prfoile )
  • Decoiler: Manual Decoiler
  • Capacity of Decoiler: 3 Ton
  • Forming Speed: 5-15m/min
  • Roller Groups: 13 stes main roller
  • Roller Material: CCr15 high grade steel with finish machining treatment, by high frequency quenched HRC58-62
  • Roller Diameter: 120mm
  • Principal Axis: 45# high grade steel with brewage treatment



   Working Flow



Manual Decoiler----Feeding Guide------Roll Forming------Hydraulic Cutting------Run out table







   Applications





Rolling shutter door, shutter door, roller shutter door, shutter door slat...





   Roller Shutter Profile Drawing









High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 0











  Main Components





  • Decoiler ----------------------------------------------- 1 Unit
  • Feeding ----------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station -------------------------------------- 1 Unit
  • PLC computer control --------------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit







   Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









   Roller  Shutter Door Forming Machine Pictures









High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 1

High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 2

High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 3











  Factory Pictures









High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 4

High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 5

High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 6









High Speed 0 - 20m/min Roller Shutter Door Slat Forming Machine With 13 Stes Main Roller 7
