Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control
Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control

Large Image :  Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-GM5
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 60-70 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
High Light:

PLC Box Gutter Roll Forming Machine

,

plc Seamless Gutter Machine

,

plc gutter molding machine




Box Gutter Roll Forming Machine / Seamless Gutter Machine With Panasonic PLC Control










  Main Specifications of Gutter Machine







  • Material thickness: 0.4-0.8mm
  • Decoiler: Manaul or hydraulic decoiler
  • Weight capacity of decoiler: 3 Ton
  • Forming Station: 16
  • Main motor power: 3KW
  • Hydraulic power: 7.5KW
  • Forming Speed: 0-15m/min
  • PLC: Panasonic Brand
  • Cutting blade material: Cr12
  • Cutting: Hydraulic cutting
  • Drive: Chain transmission
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand








  Main Components







  • Decoiler ---------------------------------------------- 1 Unit
  • Feeding guide ---------------------------------------- 1 Unit
  • main roll forming machine ---------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------ 1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table ----------------------------------------- 1 Unit









  Working Flow






Decoiler--> Coil sheet guiding and feeding --> Roll forming machine --> Cut to length --> Out-put Table







  Gutter Profile Drawing







Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 0



Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 1











  Applications





Rainwater gutter, k gutter, half round gutter, box gutter ,seamless gutter





Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 2

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 3

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 4









  Our Advantage





  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience









  Gutter Machine Pictures









Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 5

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 6













  Factory Pictures









Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 7

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 8

Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 9









Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 10









  Certificate









Box Gutter Roll Forming Machine , Seamless Gutter Machine With Panasonic PLC Control 11
