0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed

0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed

Metal Slitting Machine

Steel Slitting Machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-SSCT

Contact Us

Request A Quote
Product Details
Product Description





0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed





  Main Specifications





 1. Material specification:

  • Material: Carbon steel, GI, Color steel – Q235-Q350
  • Thickness: 0.2-2.0mm
  • Width: 400-1300mm
  • Inner diameter of coil: φ450—φ510
  • Outer diameter of coil: φ1500mm. Max.
  • Weight of coil: 5 Ton. Max.
  • Diamter of slitting blades: φ120
  • Material of slitting blades: 40Cr



2. Finished prodcuts data:

  • Tolerance of width: ≤±0.02mm
  • Max. strips to be slited: 10 pieces
  • Min. width of the pieces: 50mm





0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed 0

0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed 1







  Summary





  • This line includes Uncoiler, Feeding Guide, Slitting Machine, Cantilevering Separating, Tension Control Board, Console and General electrical equipment.
  • Electrical Source: 380V/50Hz/3Ph ( or depend on local requirement )²
  • Speed of line: 0-30m/min.
  • Main power: 30 KW
  • Floor Area accupied by machine: 10m (L) x 3m ( Width )
  • Production operation: 1 Skilled Worker, 1 common worker







  Applications





Steel slitting cutting, metal slitting , metal sheet striping,





  Our Advantage





  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
