Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips
Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

Large Image :  Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-SSCT100
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 Sets
Detailed Product Description
Floor Area Accupied By Machine: 10m (L) X 3m ( Width ) Main Power: 48 KW
Material: Carbon Steel, GI, Color Steel – Q235-Q350 Material Width: 400-1300mm
Forming Speed: 0-40m/min Inner Diameter Of Coil: φ450—φ510
High Light:

Metal Slitting Machine

,

Roll Slitting Machine

Simple Steel Coil Slitting Cutting Machine for Slitting Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips



   A). Introduction

  1. This line includes Uncoiler, Feeding Guide, Slitting Machine, Cantilevering Separating, Tension Control Board, Console and General electrical equipment.
  2. Electrical Source: 380V/50Hz/3Ph ( or depend on local requirement )
  3. Speed of line: 0-40m/min.
  4. Main power: 48 KW
  5. Floor Area accupied by machine: 10m (L) x 3m ( Width )
  6. Production operation: 1 Skilled Worker, 1 common worker



   B).  Main Components



  1. Hydraulic Decoiler -------------------------------------------------- 1 Unit
  2. Leveling and Feeding Guide ------------------------------------- 1 Unit
  3. Slitting Machine ----------------------------------------------------- 1 Unit
  4. Cantilevering Separating ------------------------------------------ 1 Unit
  5. Tension Control Board --------------------------------------------- 1 Unit
  6. Console --------------------------------------------------------------- 1 Unit
  7. General electrical equipment ------------------------------------- 1 Unit



   C). Main Specification

  1. Material: Carbon steel, GI, Color steel – Q235-Q350
  2. Thickness: 0.2-2.0mm
  3. Width: 400-1300mm
  4. Inner diameter of coil: φ450—φ510
  5. Outer diameter of coil: φ1500mm. Max.
  6. Weight of coil: 5 Ton. Max.
  7. Diameter of slitting blades: φ120
  8. Material of slitting blades: 40Cr



   D). Finished Products Data

  1. Tolerance of width: ≤±0.02mm
  2. Max. strips to be slited: 10 pieces
  3. Min. width of the pieces: 50mm



   E). Applications





Steel slitting cutting, metal slitting, metal sheet striping,





   F). Competitive Advantages



  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
  • Professional Team Support



   G). Reference Pictures



Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips 0

Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips 1
