PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm

PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm
PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm

Large Image :  PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-GTM
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard Packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Decoiler Type: Manual Or Hydraulic Type Forming Station: 13
Drive Type: Chain Transmission Material Thickness: 0.3-0.6mm
Working Speed: 0-5m/min Weight Of Machine: About 6.8 Ton
High Light:

glazed tile roll forming machine

,

ridge cap roll forming machine

PLC Frequency Control Metal Roof Tile Making Machine For Material Thickness 0.3-0.6mm





   Main Specification



PLC Frequency Control Metal Roof Tile Making Machine For Material Thickness 0.3-0.6mm
Material thickness 0.3-0.6mm
Weight Capacity Of Decoiler 5 Ton Manual Decoiler or Hydraulic Decoiler
Main Motor Power 5.5KW
Hydraulic Motor Power 5.5 Kw
Axis Diameter ¢ 76mm
Working Speed 0-5 m/min
Transporting Type Chain Transmission
Material Of Cutting Blade C r 12
Forming Stations About 13 Steps
Coil Thickness 0.3-0.6mm
Weight of Machine About 6.8 Ton
Dimension of Main Forming Machine About 11000mmX1500mmX1400mm (LxWxH)



   Product Description



  • This tile roll forming machine suits for coiled metal material, make required shape after processing of uncoiling, forming continuously pressing and cutting to length. Adopt PLC controlling system, AC frequency adjusting-speed technology, so that realize automatic production continuously
  • Different steel roof tile roll forming machines can produce different shapes of steel tile roof sheets in various thickness and colors. Steel tile roof sheets are the new substitutes for traditional clayey, concrete tiles. They are popular because of their low cost, short building period, re-cycle use, and elegant appearance. They are used a sthe roof of villas, luxury houses, theatres, exhibition centers, etc.
  • The Steel Glazed Roof Tile Roll Forming Machine is with fully automatic control system with PLC.
  • Length, quantity of sheets is adjustable.
  • Rollforming process: Decoiler, Rollforming, Pressing & Cut to length.
  • Easy operation: Key in the length and quantity on the control panel.
  • We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.



   Application



   Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel    roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



   Work Flowing



   Decoiler ---> Fedding Guide ---> Roof Tile Roll Forming ---> Pressing ---> Cut-to-length ---> Run out    table



   Components



Decoiler ---------------------------------------------- 1 Unit

Feeding guide -------------------------------------- 1 Unit

Main roll forming machine ------------------------ 1 Unit

Hydraulic pressing device -------------------------1 Unit

Hydraulic cutting device --------------------------- 1 Unit

Hydraulic Station ------------------------------------ 1 Unit

PLC computer control ------------------------------ 1 Unit

Output tables ---------------------------------------- 2 Units



   Tile Profile Drawing



PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm 0



   Advantages



  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



   Machine Pictures



PLC Control Metal Roof Tile Making Machine For Material Thickness 0.3 - 0.6mm 1
