PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission

China PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission supplier
PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission supplier PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission supplier PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission supplier PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission supplier

Large Image :  PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-GTM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard Packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Material Thickness: 0.3-0.7mm Coil Width: Custom-made
Forming Stations: 3-18 Stations (Depend On Profiles) Diameter Of Shaft: 76mm
Drive Type: Chain Transmission Forming Speed: 0-15m/min

0-12m/min Forming Speed Tile Roll Forming Machine With Material PPGI, Color Steel, GI



   Feature of Tile Roll Forming Machine



  • Different Glazed tile roll forming machines can produce different shapes of steel tile roof sheets in various thickness and colors. Steel tile roof sheets are the new substitutes for traditional clayey, concrete tiles. They are popular because of their low cost, short building period, re-cycle use, and elegant appearance. They are used a sthe roof of villas, luxury houses, theatres, exhibition centers, etc.
  • This Glazed Tile Roll Forming Machine can rollform metal roof tiles. After roll formed by this glazed roof tile roll forming machine, the surface of metal roof glazed tile is very smooth and beautiful without any scratch on the surface of tile profile sheets.
  • The Steel Glazed Roof Tile Roll Forming Machine is with fully automatic control system with PLC.
  • Length, quantity of sheets is adjustable.



      Components



       Decoiler --------------------------------------------- -1 Unit

       Feeding guide -------------------------------------- 1 Unit

       Main roll forming machine ------------------------ 1 Unit

       Hydraulic pressing device -------------------------1 Unit

       Hydraulic cutting device --------------------------- 1 Unit

       Hydraulic Station ------------------------------------ 1 Unit

       PLC computer control ------------------------------ 1 Unit

       Output tables ----------------------------------------- 2 Units



     Technical Specification



PLC Frequency Control Metal Roof Tile Making Machine For Material Thickness 0.3-0.6mm
Material Thickness 0.3-0.7mm
Coil Width Custom-made
Yield Strength 250-300 Mpa
Material PPGI,Color Steel,GI
Decoiler/Uncoiler Uncoiler Type Manual or Hydraulic or Auto Type
Coil Width Max. 1250mm
I.D 508-610mm
O.D Max. 1500mm
Tile Roll Forming Machine Forming Stations 13-18 Stations ( Depend on Profiles )
Roller material 45# steel, surface coated with 0.05mm hard chrome
Diameter of shaft 76mm
Shaft material High grade 45# steel
Drive type Chain transmission
Forming speed 0-15m/min
Main power 5.5KW
Cutting Device Cutting type Hydraulic cutting
Cutting Die Material Cr12Mov steel, HRC58-62
CuttingTolerance 10m+/-1.5mm
Encoder OMRON Brand
Hydraulic Station Hydraulic station Famous Chinese brand
Hydraulic Power 5.5KW



     Work Flowing



      Decoiler ---> Fedding Guide ---> Tile Roll Forming ---> Pressing ---> Cut-to-length ---> Run out table



      Application



       Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel               roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



      Machine Pictures



   PPGI , Color Steel , GI Material Roofing Tile Making Machine Chain Transmission
