CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed

Name: CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed
Brand: TECHWELL
SKU: TW-RSD85
Price: 1.00 USD
Availability: InStock
Rating: 5 (137 reviews)

Large Image : CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed

Product Details:

Place of Origin:	China
Brand Name:	TECHWELL
Certification:	CE
Model Number:	TW-RSD85

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contact Us
Packaging Details:	Standard packing
Delivery Time:	55-65 working days
Payment Terms:	40% T/T in advance, 60% T/T before shipment
Supply Ability:	20 sets

Contact Now

Detailed Product Description

Coil Width:	134mm(depend On Profile)	Decoiler:	Manual Decoiler
Forming Speed:	5-15m/min	Roller Groups:	13 Steps
Roller Diameter:	120mm	Principal Axis:	45# High Grade Steel With Brewage Treatment
High Light:	Garage Door Roll Forming Machine , door frame roll forming machine

CCr 15 High Grade Steel Rolling Shutter Door Roll Forming Machine For 5-15m/min Forming Speed

Main Specification of Rolling Shutter Door

Steel Sheet Thickness: 0.5-1.2mm or 1.5-2.5mm (depend on requirement )
Covered Width: 82.3mm ( depend on prfoile )
Coil Width: 134mm ( depend on prfoile )
Decoiler: Manual Decoiler
Capacity of Decoiler: 3 Ton
Forming Speed: 5-15m/min
Roller Groups: 13 stes main roller
Blade Material: CR12 with polished
Roller material: CCr15 high grade steel with finish machining treatment, by high frequency quenched HRC58-62
Roller Diameter: 120mm
Principal Axis: 45# high grade steel with brewage treatment
Type of cutting: hydraulic cutting
Voltage: 380V 50HZ 3Phases (Depend on customer requirement)
Elevtrical Control: PLC frequency control system

Main Components

Decoiler ----------------------------------------------- 1 Unit
Feeding ----------------------------------------------- 1 Unit
Main roll forming machine ----------------------------- 1 Unit
Hydraulic cutting device ------------------------------- 1 Unit
Hydraulic Station -------------------------------------- 1 Unit
PLC computer control --------------------------------- 1 Unit
Output table ------------------------------------------ 1 Unit

Profile Drawing of Rolling Shutter Door Forming Machine

CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed 0

Rolling Shutter Application

Rolling shutter door, shutter door, roller shutter door, shutter door slat...

CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed 1

Our Advantages

High Quality
Reliable
Durable
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Reference Pictures

CCr 15 High Grade Steel Rolling Shutter Forming Machine For 5-15m/min Forming Speed 2
