Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile

Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile

glazed tile roll forming machine

ridge cap roll forming machine

Place of Origin:

China

Brand Name:

TECHWELL

Certification:

CE

Model Number:

TW-PM100

Contact Us

Request A Quote
Product Details
Material Thickness:
0.3-0.7mm
Forming Speed:
0-12 M/ Min (Not Include Shear)
Forming Stations:
20 Sets
Main Power:
5.5 KW
Cutting:
Hydraulic Cutting
Material:
Galvanized Steel
Product Description

Roof Ridge Cold Roll Forming Machine Rolling for Making Color Steel Roof Ridge Profile

   A). Main Specification of Purlin Forming Machine



  • Material: Galvanized Steel
  • Material thickness: 0.3 - 0.7mm ( depend on custome’s requirement )
  • Main power: 5.5KW
  • Forming station: 20 stations
  • Weight of machine: about 8 Ton
  • Decoiler: manual decoiler
  • Weight capacity of decoiler: 3 Ton
  • Drive: Chain transmission
  • Machine post thickness: S18
  • Cutting: Hydraulic cutting
  • Hydraulic power: 3KW
  • Cutting tolence: +/-2mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand



   B). Main Components of Purlin Forming Machine


Decoiler --------------------------------------------- 1 Unit

Feeding guider -------------------------------------1 Unit

Main roll forming machine ------------------------1 Unit

Hydraulic cutting device --------------------------1 Unit

Hydraulic Station ---------------------------------- 1 Unit

PLC computer control ---------------------------- 1 Unit

Output table ---------------------------------------- 1 Unit



   C). Working Flow of Purlin Forming Machine


Decoiler --- Feeding Guider --- Roll Forming --- Cut-to-length --- Run out table



   D). Appication



Roof ridge cap, ridge cap, ridge tile; ridge valley; ridge flashing; valley flashing; top hat cap, top ridge cap.



   E). Working Flow of Guide Rail Forming Machine


Decoiling→ Guiding feeding→roll forming→cutting→running out table


   F). Competitive Advantages


1. Professional

More than 10 years' rich experience!

a.Specialized in Manual Curved Arch Roof Sheet Forming Machine;

b.Keeping improving the quality.

2. Reasonable Price

We can save your money from every part!

a. Low labor cost;

b. Convenient transportation;

c. Complete supporting industries.

3. Easy to operate

More competitive!
a. High efficiency
b. Low energy consumption

c. Reliable working

4. OEM/ ODM

Customers’ design, color & logo are accepted!

Our outstanding experts and skilled workers are devoting their hard working, to ensure the machine with high quality.

5. ONE-Years warranty, whole life service.

Keep troubles far away from you!

Within the ONE-YEARS period, we could offer the replacement parts to the client free of charge for any parts damaged due to quality problems .




   G). More Machine Pictures


Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile 0

Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile 1


   H). Factory Pictures

Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile 2


   I). Customer Visiting



Roof Ridge Cold Roll Forming Machine for Making Color Steel Roof Ridge Profile 3


   J). FAQ


1) Q: What is the Warranty Machine ?
A: For our roll forming machine , we have 1 year warranty. If any quality problems in this period ,we will take on the shipping cost and replacement.


2) Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.


3) Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly


4) Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very
beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.


5) Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.


6) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. We have good reputation in this field for ten years' experience.
