Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

China Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet supplier
Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet supplier Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet supplier Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet supplier Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet supplier

Large Image :  Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-GTM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Material: Colored Galvanized Steel Sheet Cutting Blade: Cr12 Mold Steel Quenched Treatment
Forming Machine Structural: Welding Wall Plate Thickness Of Frame Steel: 18mm
Thickness Of Coil Sheet: 0.3-0.7mm Forming Speed: 0-15m/min

Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

   Features of Tile Roll Forming Machine


1.  This roll forming machine can rollform metal roofing step tile. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.


2.  Consists of uncoiled and its base, coil sheet guidingequipment, film covering device, roll forming system, forming step effect, post-cutting equipment, hydraulic station, controlling system and supportertable


3.  Fully Automatic Control System with PLC.


4.  Easy operation: Key in the length and quantity on the control panel.


5.  We also can do a custom roll forming machine, We can design the machine according to your specification and profile drawing.


6.  One roll forming machine only can produce one profile.




   Main Components of Tile Roll Forming Machine



  • Decoiler  / Uncoiler----------------------------------------------------------------------1 Unit
  • Feeding Guide---------------------------------------------------------------------------1 Unit
  • Main Roof Step Tile Roll Forming Machine-----------------------------------------1 Unit
  • Hydraulic Pressing for Step------------------------------------------------------------1 Unit
  • Hydraulic Cutting System---------------------------------------------------------------1 Unit
  • Hydraulic Station-------------------------------------------------------------------------1 Unit
  • PLC Computer Control Box------------------------------------------------------------1 Unit
  • Support Tables---------------------------------------------------------------------------2 Units


   Technical Parameters of Glazed Step Tile Roll Forming Machine



 No. Item Parameter Remark
 1 Suitable Material Type PPGI
 Yield strength 300Mpa
 Width Depend on drawing
 Thickness 0.3-0.8mm
 2 Forming Station ≈ 17 Depend on final design
 3 Forming Speed ≈ 0-15m/min excluding cutting
 4 Roller Material High grade 45# steel With Hard Chrome
 5 Drive Type Chain Drive
 6 Shaft Diameter Φ76mm
 7 Bearing Hab Bearing
 8 Pressing Die 40CR
 9 Cutting Model Hydraulic Cutting Stop to cutting
 10Power Source Type 380V/3PH/50HZ Depend on requirement
 Main Power ≈ 7.5KW
 Hydraulic Power ≈ 5.5 KW
 11 Electric Control System PLC-PANASONIC

 Operation:
 Screen + Button

 Inverter -YASKAWA
 Touch Screen -MCGS
 Encoder -OMRON
 12  Machine Dimension ≈ 9000mmX1500mmX1500mm (LXWXH)
 13 Machine Weight ≈ 7.8T



   Glazed Roof Step Tile Forming Machine Reference Profile Drawing


Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet


Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet


   Working Flowing


Decoiler --- Fedding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out

table


   Applications of Step Tile Roll Former


Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing

sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding


   Output Table Reference Tile Products


Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet


   More Machine Pictures of Tile Roll Forming Machine

Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet


   Contact Deatails


CompanyWuxi Techwell Machienry Co.,Ltd
Website

www.wxtechwell.com
www.cold-rollformingmachine.com

E-mail / Skypesales@wxtechwell.com
Mob / Whatsapp+86-15861597732
Reference video link

https://youtu.be/N8FyrCI_Vsw
https://youtu.be/z6DkyOttmxg




Contact Details
Wuxi Techwell Machinery Co., Ltd

Contact Person: monica

Send your inquiry directly to us (0 / 3000)
