Detailed Product Description
Shaft Material: 45# Steel Material Thickness: 0.4-1.2mm
Roller Material: GCr15 Steel Power Supply: 380V, 50HZ, 3Phase
Drive Type: Gearbox Drive Forming Speed: 8-10m/min

0.4-1.2mm Octagonal Tube Pipe Roll Forming Machine Equipment With Guiding Column And Slide Blocks Forming Structure



   Description of Octagonal Tube Pipe Machine



As its name shows, Octagonal Tube is new type building material. Octagonal Tubes are widely used in petrochemical, power plant desulfurization, aerospace, ships, machinery, communications, electronics and other fields. In the market, there are two types Octagonal Tubes, seamless and interloacked. The seamless Octagonal Tube is also made by cold draw pipe making machine. Here I will mainly show the interlock Octagonal Tube pipe with the interlocked seam.



   Main Components



 Decoiler / Uncoiler  1 Unit
 Feeding Guide Device  1 Unit
 Roll Forming Machine  1 Unit
 Fly Saw Cutting  1 Unit
 PLC Control Box  1 Unit
 Output Table  1 Unit



   Main Technical Parameters



  • Coil Thickness: 0.4-1.2mm
  • Material Spec: 40mm, 60mm, 70mm, 80mm
  • Forming Speed: 8-10m/min (excluding cutting time)
  • Forming Roller: About 20 Stations (Depend on profile)
  • Main motor power:7.5KW
  • Roller Material: GCr15 steel, with quenched HRC58-62
  • Main Axis Dia. : 60mm
  • Shaft material: 45# steel
  • Cutting method: Fly saw cutting
  • Forming Structure: Guiding colum + slide blocks
  • Electrical control system: Whole line adopted PLC control
  • Cutting Tolerance: 10m +/-0.5mm
  • Drive Type: Gear box drive





   Reference Profile Drawing



0.4-1.2mm Octagonal Tube Pipe Roll Forming Machine Equipment With Guiding Column And Slide Blocks Forming Structure

0.4-1.2mm Octagonal Tube Pipe Roll Forming Machine Equipment With Guiding Column And Slide Blocks Forming Structure









   Working Flow





Uncoiling – Feed Guiding–Roll forming ––fly saw cutting – Run-out table
