Detailed Product Description
Raw Material: Color Steel, Galvanized Coil Material Width: Depend On Customer's Requirement
Motor Power: 5.5KW Forming Station: 13-22 Stations (depend On Profile Drawing)
Axis Diameter: 75mm Working Speed: 0-15m/min

Step Tile Roll Forming Machine, Wave Tile Making Machine With Color Steel, Galvanized Coil Raw Material



   Main Technical of Tile Roll Forming Machine



  • Material thickness: 0.3-0.7mm,Color Steel, Galvanised coil
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 5.5 Kw
  • Hydraulic Motor Power: 11 Kw
  • Forming Station: 13-22 ( depend on profile drawing )
  • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
  • Main Axis Material: High grade 45#, quenched and heat treatment.
  • Axis Diameter: ¢ 75mm
  • Working Speed: 0-15 m/min
  • Transporting Type: Chain Transmission
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Type of Cutting: Hydraulic cutting
  • Material Of Cutting Blade: C r 12
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Machine Frame stand: Welded structural steel
  • Thickmess of Fame Steel: 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand
  • Machine Weight: about 8.5 Ton



Main Components



Decoiler / Unoiler 1 Unit
Film Covering Device 1 Unit
Feeding Guide 1 Unit
Main Roll Fomring Machine 1 Unit
Hydraulic Pressing Device 1 Unit
Hydraulic Cutting Device 1 Unit
Hydraulic Station 1 Unit
PLC Computer Control 1 Unit
Output





Working Flowing



Decoiler --- Fedding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out



table



Step Tile Color Steel Roll Forming Machine , Galvanized Coil Wave Tiles Making Machine





Reference Profile Drawing



Step Tile Color Steel Roll Forming Machine , Galvanized Coil Wave Tiles Making Machine





Application



Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing
