High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets

High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets
High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets

Large Image :  High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets

Product Details:
Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DLM
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Detailed Product Description
Material Thickness: 0.3-0.8mm Weight Capacity Of Decoiler: 5 Ton
Material Of Cutting Blade: Cr12 Axis Diameter: ¢ 75mm
Hydraulic Motor Power: 3 Kw Material Of Roller: High Grade 45# Forge Steel
High Light:

Double Layer Roll Forming machine

,

roof cladding roll forming machine

High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets




   A). Main Specifications of Double Roof Roll Forming Machine



  • Material thickness: 0.3-0.8mm
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 7.5 Kw
  • Hydraulic Motor Power: 3 Kw
  • Forming Station: approx 18 & 18 ( depend on profile drawing )
  • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
  • Axis Diameter: ¢ 75mm
  • Working Speed: 0-15 m/min
  • Transporting Type: Chain Transmission
  • Type of Cutting: Hydraulic cutting
  • Material Of Cutting Blade: C r 12
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Machine Frame stand: Welded structural steel
  • Forming Station: approx 18 & 18 ( depend on profile drawing )
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand
  • Machine Weight: about 8.5 Ton



   B). Working Flow




Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table





   C). Main Components

  • Decoiler ------------------------------------------------ 1 Unit
  • Feeding guide ---------------------------------------- 1 Unit
  • main roll forming machine ---------------------------1 Unit
  • Hydraulic cutting device ------------------------------1 Unit
  • Hydraulic Station ------------------------------------- -1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table -------------------------------------------- 1 Unit





   D). Applications



Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding





   E). Competitive Advantages

  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience





   F). More Reference Drawings





High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets 0

 High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets 1

 High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets 2





   G). More Machine Reference Pictures



High Grade 45# Axis Double Layer Roll Former / Roll Forming Machine For Roofing Sheets 3
