0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels

China 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels supplier
0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels supplier 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels supplier 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels supplier 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels supplier

Large Image :  0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DLM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Material Thickness: 0.3-0.8mm Hydraulic Motor Power: 3 Kw
Forming Station: Approx 18 & 18 Stations Machine Weight: About 8.5 Ton
Decoiler Type: Manual Electrical Control: PLC Frequency Control System

 0 - 15m/min Forming Speed Double Layer Roll Forming Machine For Roof Wall Panels



   A). Main Specifications of Double Layer Roll Forming Machine



  • Material thickness: 0.3-0.8mm
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 7.5 Kw
  • Hydraulic Motor Power: 3 Kw
  • Forming Station: approx 18 & 18 ( depend on profile drawing )
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand
  • Machine Weight: about 8.5 Ton


   B). Working Flow

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table


   C). Main Components



 Decoiler  1 Unit
 Feeding guide  1 Unit
 Main roll forming machine  1 Unit
 Hydraulic cutting device  1 Unit
 Hydraulic station  1 Unit
 PLC computer control  1 Unit
 Output table  1 Unit






   D). Application


Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding


   E). Our Advantages

  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
  • Free Factory Visit




   F). More Reference Profile Drawings


0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels
 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels
 0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels



   G).More Reference Machine Pictures


0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels
0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels


   H).  Factory Pictures


0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels



   I). Certificates

0 - 15m/min Forming Speed Double Layer Forming Machine For Roof Wall Panels


   J). FAQ



1) Q: Do you provide installing and training overseas?
     A: Overseas machine install and worker training services are optional.

2) Q: How is your after sales support?
     A: We provide technical support on line as well as overseas services by skillful technicians.

3) Q: How does your factory do regarding quality control?
     A: There is no tolerance regarding quality control. Quality control complies with CE.
     Every machine has to past testing running before it's packed for shipment.

4) Q: How can I trust you that machines pasted testing running before shipping?
     A: 1) We record the testing video for your reference.
         2) We welcome you visit us and test machine by yourself in our factory.

5) Q: Do you have this double layer roll forming machine in stock?
     A: No, machine is made to order.

6) Q: Will you deliver the right goods as ordered? How can I trust you?
     A: Yes, we will.  We have joined Roll Forming Machine for more than ten years.
