Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment

China Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment supplier
Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment supplier Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment supplier Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment supplier Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment supplier

Large Image :  Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment

Product Details:

Place of Origin: China
Brand Name: TECHWELL
Certification: CE
Model Number: TW-DLM

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact Us
Packaging Details: Standard packing
Delivery Time: 55-65 working days
Payment Terms: 40% T/T in advance, 60% T/T before shipment
Supply Ability: 20 sets
Contact Now
Detailed Product Description
Axis Diameter: 75mm Working Speed: 0-15m/min
Thickness Of Fame Steel: 18mm Material Of Cutting Blade: Cr12
Encoder: OMRON Brand Machine Weight: About 8.5 Ton

Galvanized Steel Double Layer Roll Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment



   Main Specification of Double layer



 Material thickness 0.3-0.8mm
Material width depend on customer’s requirement
Decoiler Type manual or automatical type ( depend on customer’s requirement )
Weight Capacity Of Decoiler 5 Ton
Main Motor Power 7.5kw
Hydraulic Motor Power 3kw
Axis Diameter 75mm
Working Speed 0-15m/min
Transporting Type Chain Transmission
Heat Treatment of Cutting Blade HRC 50-60
Voltage 380V 50Hz 3phases(changeable as needs)
Material of the cutter Cr12Mov,quench treatment
Processing tolerance 10m±1.5mm
Control system Panasonic PLC control
Yield strength 235Mpa



   Working Flowing



Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table







   Components



  • Decoiler ---------------------------------------------- 1 Unit
  • Feeding guide ---------------------------------------- 1 Unit
  • main roll forming machine ---------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------ 1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table ----------------------------------------- 1 Unit



   Application



Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding



   Profile Drawing of Double Layer



Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment

Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment





   Our Advantages



  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



   Reference Pictures of Double Layer



Galvanized Steel Double Layer Forming Machine For Roof Wall Cladding With HRC50 - 60 Heat Treatment
